Green Chemistry

Green Chemistry
Principles

Green Chemistry is the utilization of a set of principles that reduces or eliminates the use or generation of hazardous substances in the design, manufacture, and application of chemical products

12 Principles of Green Chemistry:

1. Prevent Waste

Design chemical syntheses to prevent waste. Leave no waste to treat or clean up.

2. Maximize atom economy

Design syntheses so that the final product contains the maximum proportion of the starting materials. Waste few or no atoms.

3. Design less hazardous chemical syntheses

Design syntheses to use and generate substances with little or no toxicity to either humans or the environment.

4. Design safer chemicals and products

Design chemical products that are fully effective yet have little or no toxicity.

5. Use safer solvents and reaction conditions

Avoid using solvents, separation agents, or other auxiliary chemicals. If you must use these chemicals, use safer ones.

6. Increase energy efficiency

Run chemical reactions at room temperature and pressure whenever possible.

7. Use renewable feedstocks

Use starting materials (also known as feedstocks) that are renewable rather than depletable. The source of renewable feedstocks is often agricultural products or the wastes of other processes; the source of depletable feedstocks is often fossil fuels (petroleum, natural gas, or coal) or mining operations.

8. Avoid chemical derivatives

Avoid using blocking or protecting groups, or any temporary modifications if possible. Derivatives use additional reagents and generate waste.

9. Use catalysts, not stoichiometric reagents

Minimize waste by using catalytic reactions. Catalysts are effective in small amounts and can carry out a single reaction many times. They are preferable to stoichiometric reagents, which are used in excess and carry out a reaction only once.

10. Design chemicals and products to degrade after use

Design chemical products to break down to innocuous substances after use so that they do not accumulate in the environment.

11. Analyze in real-time to prevent pollution

Include in-process, real-time monitoring, and control during syntheses to minimize or eliminate the formation of byproducts.

12. Minimize the potential for accidents

Design chemicals and their physical forms (solid, liquid, or gas) to minimize the potential for chemical accidents, including explosions, fires, and releases to the environment.

Green
Solvents

In chemical manufacturing process, the selection of solvents plays a crucial role, as solvents are used in very high volumes. The extensive use of these solvents poses the significant health risks and environmental impacts, as most of them are flammable and toxic.

Therefore, it is important to select the solvents with low toxicity, minimal safety concerns, and little impact on the environment to be a greener manufacturing process.

Solvent Selection Guides:

The Innovative Medicines Initiative (IMI)-CHEM21 public-private partnership is a European consortium which promotes sustainable biological and chemical methodologies. It comprises six pharmaceutical companies from the European Federation of Pharmaceutical Industries and Associations (EFPIA) ten universities and five small to medium enterprises.

Therefore, it is important to select the solvents with low toxicity, minimal safety concerns, and little impact on the environment to be a greener manufacturing process.

Therefore, it is important to select the solvents with low toxicity, minimal safety concerns, and little impact on the environment to be a greener manufacturing process.

CHEM 21 Solvent Selection Guide (classical solvents):

These rankings are defined as below:

– Recommended (or preferred): solvents to be tested first in a screening exercise, if of course there is no chemical incompatibility in the process conditions.

– Problematic: these solvents can be used in the lab or in the Kilolab, but their implementation in the pilot plant or at the production scale will require specific measures, or significant energy consumption.

– Hazardous: the constraints on scale-up are very strong. The substitution of these solvents during process development is a priority.

– Highly hazardous: solvents to be avoided, even in the laboratory.

FamilySolventRanking
WaterWaterRecommended
AlcoholsMeOHRecommended
EtOHRecommended
i-PrOHRecommended
n-BuOHRecommended
t-BuOHRecommended
Benzyl alcoholProblematic
Ethylene glycolRecommended
KetonesAcetoneRecommended
MEKRecommended
MIBKRecommended
CyclohexanoneProblematic
EstersMethyl acetateProblematic
Ethyl acetateRecommended
i-PrOAcRecommended
n-BuOAcRecommended
EthersDiethyl etherHighly Hazardous
Diisopropyl etherHazardous
MTBEHazardous
THFProblematic
Me-THFProblematic
1,4-DioxaneHazardous
AnisoleRecommended
DMEHazardous
HydrocarbonsPentaneHazardous
HexaneHazardous
HeptaneProblematic
CyclohexaneProblematic
Me-cyclohexaneProblematic
BenzeneHighly Hazardous
TolueneProblematic
XylenesProblematic
HalogenatedDCMHazardous
ChloroformHighly Hazardous
CCl4Highly Hazardous
DCEHighly Hazardous
ChlorobenzeneProblematic
Aprotic polarAcetonitrileProblematic
DMFHazardous
DMAcHazardous
NMPHazardous
DMPUProblematic
DMSOcProblematic
SulfolanecHazardous
HMPAHighly Hazardous
NitromethaneHighly Hazardous
MiscellaneousMethoxy-ethanolHazardous
Carbon disulfideHighly Hazardous
AcidsFormic acidProblematic
Acetic acidProblematic
Ac2OProblematic
AminesPyridineHazardous
TEAHazardous
